DN200 Anti-Ultraviolet HDPE Water Pipe

Introduction of HDPE Water Pipe

PE (polyethylene) water supply pipe With its excellent performance and wide range of applications produced by polyethylene plastic material, Polyethylene (PE) is a kind of polymer material with good corrosion resistance, aging resistance and low-temperature impact resistance, so PE piping has been widely used in water treatment, natural gas transportation, urban water supply, agricultural irrigation, oil transportation and other fields by virtue of its excellent performance.

Details of HDPE Water Pipe

PE Water Pipe which are more commonly used in industrial and construction fields because of their higher density and compression resistance.PE pipes are also lighter in weight, which makes them easy to be transported and installed, and greatly reduces construction costs.

1. Temperature resistance: PE pipes have good temperature resistance, can be used normally at room temperature, and can withstand 50°C-60°C water temperature in a short time. For special requirements of high temperature environment, you can choose a specific type of PE pipe for installation.

2. Corrosion resistance: PE pipes have superior corrosion resistance and can resist the erosion of a variety of chemicals (such as acid, alkali, salt, etc.). Therefore, PE pipe is usually used for a variety of highly corrosive media transportation.

3. Impact resistance: PE pipe has strong impact resistance, can maintain good toughness and strength at low temperatures, which makes it can be used in harsh environmental conditions, not easy to rupture.

4. Wear resistance: PE pipe has smooth inner wall and low friction coefficient, which can effectively reduce the resistance of water flow and prolong the service life of the pipe. In addition, PE pipe has strong abrasion resistance, suitable for conveying sand, mud and other easy to wear media.

5. Anti-aging: PE pipe has good anti-aging properties, when used in ultraviolet radiation, oxidation and other environments, the pipe is not easy to age, and can maintain stable performance for a long time.

6. Environmental protection: PE pipe is made of environmentally friendly materials, in line with the requirements of recycling, so it does not pollute the environment and has good environmental performance.

Specifications of HDPE Water Pipe

Parameter name	Parameter value / description
Material	High-density polyethylene (HDPE)
Specification	DN20-DN1200 (can be customized）
Pressure Rating	PN6-PN25（0.6MPa-2.5MPa）
Operating Temperature Range	-20℃ to 60℃
Color	Black (with blue stripes)
Length	6m/9m/12m (customizable)
Standard	Conforms to ISO4427, GB/T13663 and other international and domestic standards
Life expectancy	50 years or more

Note:Different specifications of PE pipes are selected according to the actual needs to ensure that they can meet the requirements of installation conditions and use environment.

Applications of HDPE Water Pipe

1. water supply system:

PE pipes are widely used in urban water supply, rural water pipe network construction and other fields, especially suitable for underground water supply system.PE pipes are not easy to corrode, have a long service life, is the ideal choice for water supply pipeline.

2. Drainage system:

PE pipes are also widely used in urban drainage, sewage treatment and other fields. As PE pipes have good corrosion resistance, they can resist the erosion of chemicals contained in sewage, and are widely used in sewage transportation piping systems.

3. Natural gas transportation:

PE pipes are widely used in natural gas transportation system. As the transportation of natural gas requires corrosion-resistant and pressure-resistant pipes, PE pipes have these advantages and are an important choice for natural gas transportation.

4.Agricultural irrigation:

PE pipes are used in agriculture for irrigation systems, especially sprinkler and drip irrigation systems. Its corrosion resistance, UV aging resistance and high temperature resistance make it an ideal pipe for agricultural irrigation.

5.Industrial Piping:

PE pipes are suitable for chemical, petroleum, food, pharmaceutical and other industrial fields, capable of transporting a variety of corrosive liquids, gases and solid particles.

6.Power cable protection pipe:

PE pipe as power cable protection pipe has excellent mechanical properties, which can protect the cable from external damage and extend the service life of the cable.

Packing and Shipment

Pipe dia. dn20-63mm be in coils with 100m/200m length

Pipe dia. Dn75-1200mm be packed in bars with 5.8m or 11.8m length

Shipment:By sea,railway,by air or as customer’s request.

Company Profile

Luoyang Datang Energy Tech Co.Ltd was established in 2015 and located in High-tech development zone, Luoyang City, covers a large area with state-of-the-art facilities. Our government offers a supportive environment, including convenient transportation and access to essential resources. Since inception in 2015, we have been committed to excellence in pipes and fittings, continuously innovating to meet market demands.

If you need PPR Pipes and Fittings,Please feel free to contact us(sales@pipesandfittings.net)

Payment Terms

T/T,L/C at sight,Western Union & Paypal,etc.

FAQ of HDPE Water Pipe

Q1. How is the corrosion resistance of HDPE Water Pipe?

PE pipe has excellent corrosion resistance and can resist the erosion of most chemicals, including acid, alkali, salt, sewage and so on. It is an ideal material for conveying corrosive liquids and gases.

Q2. Can HDPE Water Pipe be used in low temperature environment?

PE piping has good low-temperature impact resistance and can be used normally in environments ranging from -40°C to 50°C. However, it is necessary to choose the type of piping that is suitable for use in low-temperature conditions (e.g., PE piping with added antifreeze).

Q3. What are the connection methods for HDPE Water Pipe?

The common connection methods for PE pipes are heat fusion connection, electrofusion connection and mechanical connection. Thermal fusion connection is to heat both ends of the pipe to a melted state, and then pressurize the connection to form a sealed joint; electrofusion connection uses electrofusion fittings, which are connected by electric heating; mechanical connection uses flanges, threads, and other traditional ways of connection.

Q4. Can HDPE Water Pipe be recycled?

PE pipes are environmentally friendly materials and can be recycled, in line with modern environmental requirements. Waste PE pipes can be recycled through reprocessing to reduce the waste of resources.

Q5. How long is the service life of HDPE Water Pipe?

The service life of PE water supply pipes is usually more than 50 years, and under normal use and maintenance, PE pipes can continue to provide reliable service. Its corrosion and aging resistance is strong, and it will not be easily ruptured or deformed under long-term use.

Q6. What kind of media can HDPE Water Pipe transport?

PE pipes can be used to convey a wide range of media, such as clear water, drinking water, sewage, natural gas, chemicals, mud, sand, etc. Depending on the material grade of the pipe and the required working pressure, different types of PE pipes can be selected.
